Ultima
The Ultima lighting fixture is a versatile and energy-efficient choice for any space. It can be used as a recessed or semi-surface mounted downlighter, which features side glow light emitting possibilities for a decorative effect. With very low UGR values, it provides unmatched visual comfort.
- 2000 lumen
- Max. 20 Watt
- >80
> Information
20 Watt design downlighter.
Typical applications
All possible applications where users want to save on both energy- and maintenance costs by implementing a pure Dutch Design & Made high quality LED Lighting system.
Recessed and semi surface mounted usage
The Ultima can be installed both as recessed and semi-surface mounted downlighter.
Side glow light emitting possibilities
When choosing the transparent backplate, the Ultima offers the possibility for a decorative side glow effect in combination with the use as a functional downlighter.
Very low UGR values for optimum comfort
Due to the shape of the front, the Ultima offers an extremely low UGR value of < 13.
This value ensures unmatched visual comfort for working conditions in offices.
Choice of not less than 5 different beam angles
All possible dimming methods available
Number of DMX channels needed per LED colour
Number of DMX channels needed | ||||
LED colour | 1 | 2 | 3 | 4 |
Single colour | ||||
Tunable White | ||||
ColourFlow |
Downloads and accessories
Led colours
Lenses
Control methods
Mounting
Warranty
> Specifications
Type | Ultima, Downlighter |
Colour | White or black |
Material | Aluminum & PC/ABS V0 |
Weight | 450 gram |
Mounting hole | 12 cm |
Installation depth | 10 cm |
Optics | 8º | 12º | 30º | 60º | 80º | 12x46º |
Light source | High Power LED |
Light output | 2000 lumen |
CRI | >80 |
LED colours | 2700K | 3000K |
Power consumption | Max. 20 Watt |
Drive current | 700mA |
Driver | Driver included | Driver external |
Dimming | Mains dimmable | 1-10V dimmable | DALI | Casambi | DMX512 |
Connection | CLS Smart connect system |
IP rating | IP 20 |
Protection class | 3 |
Energy label | A |
Lifetime | 50000 |
LB Value | L90B10 at 50.000h |
Warranty | 5 years |
Remarks | Very low glare: UGR value < 13, side glow effect possible |
> Photometrics
These are the Photometric and LDT files for the most popular configuration(s). Please contact us via info@cls-led.com if your choice is missing from the list.
- LM79_ULTIMA_2700K_CRI80_8DEG
- LM79_ULTIMA_2700K_CRI80_12DEG
- LM79_ULTIMA_2700K_CRI80_30DEG
- LM79_ULTIMA_2700K_CRI80_54DEG
- LM79_ULTIMA_2700K_CRI80_12x46DEG
- LM79_ULTIMA_3000K_CRI80_8DEG
- LM79_ULTIMA_3000K_CRI80_12DEG
- LM79_ULTIMA_3000K_CRI80_30DEG
- LM79_ULTIMA_3000K_CRI80_54DEG
- LM79_ULTIMA_3000K_CRI80_12x46DEG
- Download the LDT files
