Krypton

The Krypton offers both high CRI white light for general lighting applications, and mood creating coloured light settings. Due to its high effective lumen output, the Krypton is the perfect lighting solution for large and high venues. The fixture is completely silent in use, as it uses no fans.

  • 93 watt
  • CRI >80, >90

> Information

High Quality white light + RGB LED light source

The Krypton uses a large COB LED module for the white light. A choice of several colour temperatures & CRI values are available. As the white light component of the units is a pure white light module, there is no risk of so called colour shifting as is often seen with fixtures that use RGBW/RGBA LED modules to create white light. The RGB modules are fitted with the latest generation of high power LED’s.

Fully integrated DMX electronics

The Krypton offers different dimming methods:
> Hybrid dimming.
> Full Analog dimming.

Camera flickering is no longer an issue with the Hybrid or Full Analogue dimming setting. Soft, smooth dimming to very low levels is ensured with the special Dynamic Soft Dim channel.

Modular design

As the krypton series are fully modular built, the fixture has the possibility to be upgraded to future developments, ensuring that the units can never be outdated. Due to the very effective heat sink, there is no need for active cooling, ensuring that maintenance activities are kept to a minimum. Choose your own data connecting system Daisy-chaining the signal is possible with a choice of:
> Neutrik Ethercon RJ45 connectors.
> XLR 3 pole.
> XLR 5 pole.
> Wireless DMX.

Multiple mounting possibilities

The Krypton can be used with the available accessories as a: Floor standing fixture or as a bracket/pendant mount fixture.

Accessories

A honey comb louvre is available for the Krypton. With this available option, lighting designers can create the perfect light setting in each environment.

Typical applications

The applications are numerous. Concert halls, theatres, event centres, houses of worships and other spaces where one wants to have high quality white light with the possibility of creating different moods by programming colours.

Downloads

Led colours

2700K3000K4000KRGB

Lenses

White LED 24ºWhite LED 35ºWhite LED 60ºRGB 10ºRGB 25ºRGB 35º

Control methods

Mounting

> Specifications

TypeKrypton, Surface mounted fixture for general & effect lighting
ColourBlack, white
MaterialPowder coated aluminium
Weight2500 gram
Swivel horizontal, 180 vertical

OpticsWhite LED 24º | White LED 35º | White LED 60º | RGB 10º | RGB 25º | RGB 35º
Light sourceLumileds
Power consumption93 watt
CRI>80, >90
Led colours2700K | 3000K | 4000K
RGB

Drive current100~240 VAC
DriverDriver included | Driver internal
DimmingDMX512 | Wireless DMX | DMX Analog dimmable | DMX Hybrid dimmable

Lifetime50.000 h
Warranty5 years

IP ratingIP 20 | IP
Protection class1
CertificationsCE

AccessoriesHoney comb louvre
RemarksPassive cooling, completely silent
Theatre and stage lighting fixture with rgb and white led

> Photometrics

These are the Photometric and LDT files for the most popular configuration(s). Please contact us via info@cls-led.com if your choice is missing from the list.
