Jade Zoom

The Jade Zoom is a versatile and powerful LED lighting fixture. With a zoom range from 9° to 58° (Bridgelux) or 11° to 67° (Xicato), it is ideal for museum, gallery, or high-end retail lighting. The advanced optical system ensures uniform light quality, while the choice of LED light sources allows for a perfect fit to the lighting plan.

  • 1500 - 2000 lumen
  • Max. 25 - 35 Watt
  • CRI ~90 or ~98
Get a quote
Configurator

> Information

CLS Performance Zoom

Zoom range from 9° to 58°! (Bridgelux)
Zoom range from 11° to 67°! (Xicato)

Unmatched uniform light quality & light output

A very advanced optical system ensures an unmatched uniform light image. Due to the unique CLS DFC lens, the Jade Zoom offers a higher effective light output than other comparable fixtures with zoom capability. The CLS DFC lens is a glass lens with a very high optical purity, combined with some unique features that contribute to a high level of light efficiency.

Large choice of LED light sources

The Jade Zoom is available with a Xicato Artist-, or for CLS a special developed Bridgelux LED light source. The Xicato Artist series is the first choice of many light designers, when it comes to the quality of light. It offers a CRI of ~98, with a R9 value of ~95 (3000K version)

Large choice in dimming methods

Local dim, DALI, DMX, Casambi Bluetooth, Wireless DMX, and Casambi + Local Dim in one track adapter.

Large choice of accessories

The Jade Zoom Series product line offers many accessories to help designers create the perfect light setting.

Multiple mounting options

Track mounting with choice in both Global or Eutrac rail adapters.
Ceiling mounting by means of a threaded end. (Jade B Zoom)

Compatibilities

Number of DMX channels needed per LED colour

Number of DMX channels needed
LED colour 1 2 3 4
Single colour
Tunable White
ColourFlow
To read more about DMX, click here

Downloads and accessories

Led colours

2700K3000K3500K4000K

Lenses

9°- 58°11°- 67°

Control methods

Mounting

Warranty

Detailed specifications

> Related projects

> Specifications

TypeJade Zoom, 25 or 35 Watt track or surface mounted spot
ColourBlack, white or grey
MaterialAnodized or coated aluminium & PC/ABS V0
Weight955 gram
Swivel340° horizontal | 350° vertical
Optics9°- 58° | 11°- 67°
Light sourceBridgelux or Xicato
Light output1500 - 2000 lumen
CRI~90 or ~98
LED colours2700K | 3000K | 3500K | 4000K
Power consumptionMax. 25 - 35 Watt
Power supply180~264 VAC
DriverDriver included | Driver internal
DimmingMains dimmable | Local dim | DALI | Casambi | DMX512 | Wireless DMX | Local Dim + Casambi
ConnectionTrack adapter, Global or Eutrac
IP ratingIP 20
Protection class1
CertificationsCE
Lifetime50.000h
LB ValueL90B10 at 50.000h
Warranty5 years
AccessoriesA customizable snoot that can be build up in segments of 2 cm. Rotatable barndoor, Beam shapers and Honeycomb louvre.
RemarksThe beam angle can be adjusted from the backside of the fixture.
Jade Zoom Track Zoomable Lighting Fixture in black and white

> Photometrics

These are the Photometric and LDT files for the most popular configuration(s). Please contact us via info@cls-led.com if your choice is missing from the list.
